Produktbeskrivning
Dual, 4.5MHz, BiMOS Operational Amplifier with MOSFET Input/Bipolar Output
The CA3240 is the dual version of the popular CA3140 integrated circuit operational amplifier. It combines the advantages of MOS and bipolar transistors on the same monolithic chip. The gate-protected MOSFET (PMOS) input transistors provide high input impedance and a wide common-mode input voltage range (typically to 0.5V below the negative supply rail). The bipolar output transistors allow a wide output voltage swing and provide a high output current capability.
Features
* Dual Version of CA3140
* Internally Compensated
* MOSFET Input Stage
- Very High Input Impedance (Zin) 1.5TOhm (Typ)
- Very Low Input Current (Iin) 10pA (Typ) at +/-15V
- Wide Common-Mode Input Voltage Range (VICR): Can Be Swung 0.5V Below Negative Supply Voltage Rail
* Directly Replaces Industry Type 741 in Most Applications
Applications
* Ground Referenced Single Amplifiers in Automobile and Portable Instrumentation
* Sample and Hold Amplifiers
* Long Duration Timers/Multivibrators (Microseconds-Minutes-Hours)
* Photocurrent Instrumentation
* Intrusion Alarm Systems
* Active Filters
* Comparators
* Function Generators
* Instrumentation Amplifiers
* Power Supplies
The CA3240 is the dual version of the popular CA3140 integrated circuit operational amplifier. It combines the advantages of MOS and bipolar transistors on the same monolithic chip. The gate-protected MOSFET (PMOS) input transistors provide high input impedance and a wide common-mode input voltage range (typically to 0.5V below the negative supply rail). The bipolar output transistors allow a wide output voltage swing and provide a high output current capability.
Features
* Dual Version of CA3140
* Internally Compensated
* MOSFET Input Stage
- Very High Input Impedance (Zin) 1.5TOhm (Typ)
- Very Low Input Current (Iin) 10pA (Typ) at +/-15V
- Wide Common-Mode Input Voltage Range (VICR): Can Be Swung 0.5V Below Negative Supply Voltage Rail
* Directly Replaces Industry Type 741 in Most Applications
Applications
* Ground Referenced Single Amplifiers in Automobile and Portable Instrumentation
* Sample and Hold Amplifiers
* Long Duration Timers/Multivibrators (Microseconds-Minutes-Hours)
* Photocurrent Instrumentation
* Intrusion Alarm Systems
* Active Filters
* Comparators
* Function Generators
* Instrumentation Amplifiers
* Power Supplies
