Produktbeskrivning
Green Mode Fairchild Power Switch
The FSDL0165RN is an integrated Pulse Width Modulator (PWM) and Sense FET specifically designed for high performance offline Switch Mode Power Supplies (SMPS) with minimal external components. This device is an integrated high voltage power switching regulator which combine an avalanche rugged Sense FET with a current mode PWM control block.
Features
* Internal Avalanche Rugged Sense FET
* Consumes only 0.65W at 240VAC & 0.3W load with Advanced Burst-Mode Operation
* Frequency Modulation for low EMI
* Precision Fixed Operating Frequency
* Internal Start-up Circuit
* Pulse by Pulse Current Limiting
* Abnormal Over Current Protection
* Over Voltage Protection * Over Load Protection
* Internal Thermal Shutdown Function
* Auto-Restart Mode
* Under Voltage Lockout
* Low Operating Current (3mA)
* Adjustable Peak Current Limit
* Built-in Soft Start
Applications
* SMPS for VCR, SVR, STB, DVD & DVCD
* SMPS for Printer, Facsimile & Scanner
* Adaptor for Camcorder
