Produktbeskrivning
QUADRUPLE HALF-H DRIVERS
The L293D is a quadruple high-current half-H driver. The L293D is designed to provide bidirectional drive currents of up to 600-mA at voltages from 4.5 V to 36 V. It can drive inductive loads such as relays, solenoids, dc and bipolar stepping motors, as well as other high-current/high-voltage loads in positive-supply applications.
Features
* Wide Supply-Voltage Range: 4.5V to 36V
* Separate Input-Logic Supply
* Internal ESD Protection
* Thermal Shutdown
* High-Noise-Immunity Inputs
* Functionally Similar to SGS L293D
* Output Current 600mA Per Channel
* Peak Output Current 1.2A Per Channel
* Output Clamp Diodes for Inductive Transient Suppression
The L293D is a quadruple high-current half-H driver. The L293D is designed to provide bidirectional drive currents of up to 600-mA at voltages from 4.5 V to 36 V. It can drive inductive loads such as relays, solenoids, dc and bipolar stepping motors, as well as other high-current/high-voltage loads in positive-supply applications.
Features
* Wide Supply-Voltage Range: 4.5V to 36V
* Separate Input-Logic Supply
* Internal ESD Protection
* Thermal Shutdown
* High-Noise-Immunity Inputs
* Functionally Similar to SGS L293D
* Output Current 600mA Per Channel
* Peak Output Current 1.2A Per Channel
* Output Clamp Diodes for Inductive Transient Suppression
