Produktbeskrivning
Wide-Bandwidth, Low-Power, Single-Supply, Rail-to-Rail I/O Op Amp
The MAX4130-MAX4134 family of operational amplifiers combines 10MHz gain-bandwidth product and excellent DC accuracy with Rail-to-Rail operation at the inputs and outputs. These devices require only 900uA per amplifier, and operate from either a single supply (+2.7V to +6.5V) or dual supplies (+/-1.35V to +/-3.25V) with a common-mode voltage range that extends 250mV beyond VEE and VCC. They are capable of driving 250ohm loads and are unity-gain stable.
Features
* +2.7V to +6.5V Single-Supply Operation
* Rail-to-Rail Input Common-Mode Voltage Range
* Rail-to-Rail Output Voltage Swing
* 10MHz Gain-Bandwidth Product
* 900uA Quiescent Current per Amplifier
* 200uV Offset Voltage
* No Phase Reversal for Overdriven Inputs
* Drive 250ohm Loads
* Stable with 160pF Capacitive Loads
* Unity-Gain Stable
Applications
* Battery-Powered Instruments
* Portable Equipment
* Data-Acquisition Systems
* Signal Conditioning
* Low-Power, Low-Voltage Applications
The MAX4130-MAX4134 family of operational amplifiers combines 10MHz gain-bandwidth product and excellent DC accuracy with Rail-to-Rail operation at the inputs and outputs. These devices require only 900uA per amplifier, and operate from either a single supply (+2.7V to +6.5V) or dual supplies (+/-1.35V to +/-3.25V) with a common-mode voltage range that extends 250mV beyond VEE and VCC. They are capable of driving 250ohm loads and are unity-gain stable.
Features
* +2.7V to +6.5V Single-Supply Operation
* Rail-to-Rail Input Common-Mode Voltage Range
* Rail-to-Rail Output Voltage Swing
* 10MHz Gain-Bandwidth Product
* 900uA Quiescent Current per Amplifier
* 200uV Offset Voltage
* No Phase Reversal for Overdriven Inputs
* Drive 250ohm Loads
* Stable with 160pF Capacitive Loads
* Unity-Gain Stable
Applications
* Battery-Powered Instruments
* Portable Equipment
* Data-Acquisition Systems
* Signal Conditioning
* Low-Power, Low-Voltage Applications
