Produktbeskrivning
8-bit Microcontroller based on the PIC RISC architecture.
Max CPU operating frequency: 20MHz
EPROM Program Memory: 1024 words
RAM: 68B
Features
* Power-on Reset (POR)
* Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
* Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
* Programmable code-protection
* Power saving SLEEP mode
* Selectable oscillator options
* Low-power, high-speed CMOS EPROM technology
* Fully static design
* Wide operating voltage range: 2.5V to 6.0V
* High Sink/Source Current 25/25 mA
* Timer0: 8-bit timer/counter with 8-bit prescaler
* 8-bit 4-channel analog-to-digital converter
* Brown-out detection circuitry for Brown-out Reset (BOR)
* 13 I/O Pins with Individual Direction Control
