Produktbeskrivning
- Hall effect-based sensor with electrically isolated current path allows the sensor to be inserted anywhere along the current path and to be used in applications that require electrical isolation.
- Differential Hall sensing rejects common-mode fields, so the orientation of the sensor relative to uniform external magnetic fields (e.g. the Earth’s magnetic field) has less effect on the measurement.
- The conductive path internal resistance is typically 0.6 mΩ, and the PCB is made with 2-oz copper, so very little power is lost in the module.
- High-bandwidth 120 kHz analog output voltage proportional to AC or DC currents.
- Less than 5 µs response time.
- Output is not ratiometric (i.e. the zero point and sensitivity are independent of the actual supply voltage), which provides immunity from noisy supplies.
- Overcurrent fault output with 1.5 µs response time indicates when the current exceeds the optimized sensing range and can be used for fast short-circuit detection.
- Integrated digital temperature compensation circuitry allows for near closed loop accuracy over temperature in an open loop sensor.
- Automotive-grade operating temperature range of -40°C to 125°C.
