Produktbeskrivning
1A DC Motor Driver
TLE 4205 is an integrated power full-bridge DC-motor driver for a wide temperature range, as required in automotive applications for example. The circuit contains two power comparators that can be combined to a full-bridge circuit. For inductive loads there are integrated free-wheeling diodes to + VS and ground. The outputs are shortcircuit proof up to 18V supply voltage to ground and turn off when overtemperature occurs. This IC is especially suitable for headlight-beam adjustment in automobiles.
Features
* Max. driver current 1A
* Integrated free-wheeling diodes
* Short-circuit proof to ground
* Inhibit
* ESD protected inputs
* Temperature range -40C to +150C
TLE 4205 is an integrated power full-bridge DC-motor driver for a wide temperature range, as required in automotive applications for example. The circuit contains two power comparators that can be combined to a full-bridge circuit. For inductive loads there are integrated free-wheeling diodes to + VS and ground. The outputs are shortcircuit proof up to 18V supply voltage to ground and turn off when overtemperature occurs. This IC is especially suitable for headlight-beam adjustment in automobiles.
Features
* Max. driver current 1A
* Integrated free-wheeling diodes
* Short-circuit proof to ground
* Inhibit
* ESD protected inputs
* Temperature range -40C to +150C
