LED power supply 350mA 12W - constant current

350mA 12W electrical transformer. Suitable for LED spotlights, LED luminaires and LED modules that require 350mA current limiting. Low profile model for new installation or for replacement of existing driver in luminaire. Protected against short circuit, overheating and overload.

Note that when connecting constant current LED light sources, these should be connected in series after the driver.

Specifications:

Type CC/CV: Constant current (CC)
Voltage range (DC): 19-34V
Constant current: 350mA
Power: 12W
Minimum load: 7W
Dimensions: 127.3x50.1x11.2 mm
Weight: 60g
Input voltage range: 220-240V (AC)
Power in standby mode: 0.32W
Protection class: IP20
Dimmable: No
Input connection: 2x0.75 mm2, screw terminal
Output connection: 2x0.75 mm2, screw terminal
Markings: Haus, WEEE, CE
Operating temperature: -20 to 45 degrees C
