Product description
The 22.86 x 22.86 mm Nicla Voice allows for easy implementation of always-on speech recognition on the edge, because it integrates Syntiant's powerful NDP120 Neural Decision processor to run multiple AI algorithms, leveraging bio-inspired, advanced machine learning to automate complex tasks.
Nicla Voice comes with a comprehensive package of sensors: in addition to its microphone, it features a smart 6-axis motion sensor and a magnetometer, making it the ideal solution for predictive maintenance, gesture/voice recognition and contactless applications.
Nicla Voice offers onboard Bluetooth® Low Energy connectivity to easily interact with existing devices, and is compatible with Nicla, Portenta and MKR products.
Finally, its ultra-low power consumption makes 24/7 always-on sensor data processing possible, with the option of battery-powered standalone operation.
Small enough to fit into wearables or retrofit existing machinery, enabling AI yet requiring minimal energy: Nicla Voice is the "impossible" combination that makes voice recognition on the edge possible - and easier than ever.
Microprocessor
* Syntiant® NDP120 Neural Decision Processor (NDP):
* 1x Syntiant Core 2 ultra-low-power deep neural network inference engine
* 1x HiFi 3 Audio DSP
* 1x Arm® Cortex® M0 core up to 48 MHz
Microcontroller
* Nordic Semiconductor nRF52832:
* 64 MHz Arm® Cortex M4
Sensors
* High performance microphone (IM69D130)
* 6-Axis IMU (BMI270)
* 3-axis magnetometer (BMM150)
I/O
* 1x I2C bus (with ESLOV connector)
* 1x serial port
* 1x SPI
* 2x ADC
* Programmable I/O voltage from 1.8-3.3V
Interface
* External microphone connector (ZIF)
* USB interface with debug functionality
Memory
* 512KB Flash / 64KB SRAM * 16MB SPI Flash for storage
* 48KB SRAM dedicated for NDP120
Dimensions and weight
* 22,86 x 22,86 mm
* 2 g
Operating temperature
* 0° C to +85° C (32° F to 185°F)
Power
* High speed USB (500mbps)
* Pin Header
* 3.7V Li-po battery with Integrated battery charger and fuel gauge (BQ25120AYFPR)
Connectivity
* Bluetooth® Low Energy (ANNA-B112)
