DC-DC converter step-up/step-down 1.25-25V 5A

DCDC-converter based on the LM2577 and LM2596. The module is an efficient way of converting a higher voltage to a lower (step-down) or a lower voltage to a higher (step-up). The output voltage is set using the on-board trimmer. This module can also limit the output current for the connected load from around 100mA up to 3A. The module should be actively cooled when used in high ambient temperatures, and/or when powering larger loads to prevent shutdown. This module is not intended for adjustment during use. Adjust the voltage before connecting any load.

* Input voltage: 4 - 25VDC
* Output voltage: 1.25 - 25VDC
* Max current: 3A
* Maximum efficiency: 80%
* Size: 49.3 x 38.1 x 13.9mm
