Product description
Flat flexible PVC insulated coupling cable for low voltage. Has two parallel conductors, red and black. Intended for power supply (AC or DC), hook-up wire, low voltage lighting, signal transmission or loudspeakers. Sold by the meter. Max length (roll) is 100m.
Specifications:
- Conductor material: Cu, OFC (pure copper)
- Conductor wire cross-section: 2x0.5 mm² AWG20
- Number of conductors: 2 pcs
- Conductor type: Multicore (stranded)
- Multicore assembly: 2x 16x0.2 mm
- Jacket color: Red/black
- Jacket material: PVC
- Insulation: single insulated
- Outer dimensions: 2.2x4.4 mm
- Rated voltage: 50V
- Temperature range -5 to +75 °C
- Fire class (CPR): Eca
