Product description
100 meter flat flexible PVC insulated coupling cable for low voltage. Has two parallel conductors, red and black. Intended for power supply (AC or DC), hook-up wire, low voltage lighting, signal transmission or loudspeakers.
Specifications:
- Conductor material: CCA (copper clad aluminium)
- Conductor wire cross-section: 2x2.5 mm² AWG13
- Number of conductors: 2 pcs
- Conductor type: Multicore (stranded)
- Multicore assembly: 2x 50x0.25 mm
- Jacket color: Red/black
- Jacket material: PVC
- Insulation: single insulated
- Outer dimensions: 4.0x8.0 mm
- Rated voltage: 50V
- Temperature range -10 to +70 °C
- Fire class (CPR): Eca
What is CCA?
The abbreviation stands for Copper Clad Aluminum which means that the conductor is made of copper plated aluminum wire. The aluminum core does not affect high-frequency signals, but it does affect DC transmission and low-frequency signals (e.g. audio). This is due to its slightly higher resistance. The higher resistance can be compensated for by choosing a CCA cable with a slightly larger conductor area. In the context of loudspeakers, the higher resistance results in some power loss but no hearable difference in sound quality (although this is disputed among audiophiles).
