Connector GX12 jack 2-pin

GX12 is a series of connectors for general purposes and is commonly used for sensors, batteri charging, automation/industry and audio/video. The connectors feature a screw lock and are polarizing. Conductors are soldered to solder cups. The cable connectors has a screwed strain-relief and fits cables with up to 5mm outer diameter.

* Max voltage: 125VAC
* Max current: 3A
* Max cable area: 0.5mm²
