Product description
Quad Differential Comparator
This device consist of four independent voltage comparators that are designed to operate from a single power supply over a wide range of voltages. Operation from dual supplies also is possible, as long as the difference between the two supplies is 2V to 36V, and Vcc is at least 1.5V more positive than the input common-mode voltage. Current drain is independent of the supply voltage. The outputs can be connected to other open-collector outputs to achieve wired-AND relationships.
Features
* Single Supply or Dual Supplies
* Wide Range of Supply Voltage:
- Max Rating . . . 2V to 36V
- Tested to 30V
* Low Supply-Current Drain Independent of Supply Voltage . . . 0.8mA Typ
* Low Input Bias Current . . . 25nA Typ
* Low Input Offset Voltage . . . 2mV Typ
* Common-Mode Input Voltage Range Includes Ground
* Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . +/-36V
* Low Output Saturation Voltage
* Output Compatible With TTL, MOS, and CMOS
