Product description
Mean Well LRS-200-12. Compact switched-mode power supply with a fixed output of 12VDC / 100W. Screw terminals for all connections. Trimpot for output voltage adjustment. Protected against overload, overvoltage and short circuit.
Specifications:
- Product type: Switched-mode power supply for installation
- Manufacturer: Mean Well
- Input voltage: 85 - 264VAC / 120 - 373VDC
- Output voltage: 12VDC (10.2 - 13.8V)
- Output current: 8.5A
- Power output: 100W
- Efficiency: 88%
- Max ripple: 120mVpp
- Dimensions: 129x97x30mm
For more specifications, see datasheet.
