Product description
Compact switched power supply with two fixed voltage outputs, 5VDC and 12VDC. Screw terminals for all connections. Trimmer for adjusting the output voltage. Protected agains overload, over-voltage and short-circuit.
* Input voltage: 88 - 264VAC / 125 - 373VDC
* Output voltage: 4.75 - 5.5VDC / +12VDC / -12VDC
* Output current: 5A (5V) / 2.5A (+12V) / 1A (-12V)
* Power rating: 50W
* Efficiency: 77%
* Maximum ripple: 80mVpp / 120mVpp / 120mVpp
* Dimensions: 99 x 97 x 36mm
* Input voltage: 88 - 264VAC / 125 - 373VDC
* Output voltage: 4.75 - 5.5VDC / +12VDC / -12VDC
* Output current: 5A (5V) / 2.5A (+12V) / 1A (-12V)
* Power rating: 50W
* Efficiency: 77%
* Maximum ripple: 80mVpp / 120mVpp / 120mVpp
* Dimensions: 99 x 97 x 36mm
