Product description
Intel® Curie module dual-core ((Intel® Quark processor core and ARC* core) with Bluetooth® low energy, 6-axis combo sensor and pattern matching engine
14 digital input/output pins (four can be used as PWM output pins)
Four PWM output pins
Six analog input pins
Strictly 3.3 V I/Os only
20 mA DC current per I/O pin
196 kB Flash memory
24 kB SRAM
32 MHz clock speed
USB connector for serial communication and firmware updates (DFU protocol)
35 mm length and 26 mm width
14 digital input/output pins (four can be used as PWM output pins)
Four PWM output pins
Six analog input pins
Strictly 3.3 V I/Os only
20 mA DC current per I/O pin
196 kB Flash memory
24 kB SRAM
32 MHz clock speed
USB connector for serial communication and firmware updates (DFU protocol)
35 mm length and 26 mm width
