Product description
Low noise JFET single operational amplifier
The TL071 is a high-speed JFET input single operational amplifier. This JFET input operational amplifier incorporates well matched, high-voltage JFET and bipolar transistors in a monolithic integrated circuit. The device features high slew rates, low input bias and offset currents, and low offset voltage temperature coefficient.
Features
* Wide common-mode (up to Vcc+) and differential voltage range
* Low input bias and offset current
* Low noise en = 15nV/vHz (typ)
* Output short-circuit protection
* High input impedance JFET input stage
* Low harmonic distortion: 0.01% (typ)
* Internal frequency compensation
* Latch-up free operation
* High slew rate: 16V/us (typ)
